Steel Deck Roll Forming Machine For Floor Decking Sheets The Philippines 1220mm

Steel Deck Roll Forming Machine For Floor Decking Sheets The Philippines 1220mm
Steel Deck Roll Forming Machine For Floor Decking Sheets The Philippines 1220mm Steel Deck Roll Forming Machine For Floor Decking Sheets The Philippines 1220mm Steel Deck Roll Forming Machine For Floor Decking Sheets The Philippines 1220mm Steel Deck Roll Forming Machine For Floor Decking Sheets The Philippines 1220mm Steel Deck Roll Forming Machine For Floor Decking Sheets The Philippines 1220mm

Μεγάλες Εικόνας :  Steel Deck Roll Forming Machine For Floor Decking Sheets The Philippines 1220mm

Λεπτομέρειες:
Place of Origin: Botou Hebei China
Μάρκα: HC
Πιστοποίηση: CE
Model Number: HC51-180-1105
Πληρωμής & Αποστολής Όροι:
Minimum Order Quantity: 1set
Packaging Details: Main machine is nude, the computer control box is packed by carton box.
Delivery Time: 30days
Payment Terms: L/C,T/T
Supply Ability: 20 sets/month

Steel Deck Roll Forming Machine For Floor Decking Sheets The Philippines 1220mm

περιγραφή

Description:

Main parameter

No.

   Main parameter of Floor Deck Roll Forming Machine

1

Suitable to process

Color steel plate

2

Width of the plate

1220mm

3

Rollers

24 rows

4

Dimensions

12.7*1.85*1.61m

5

Power

11+11+7.5kw

6

Rolling material

shaft bearing steel(quenching)

6

Thickness of the plate

1mm

7

Productivity

15m/min

8

Diameter of the roller

Φ90mm

9

Voltage

220V 60Hz 3phases

10

Material of the cutting plate

Cr12

11

Hydraulic

46#

12

Processing precision

Within 1.00mm

13

Control system

PLC control


Equipment components: Man-made uncoiler-roll forming machine-computer control system-hydraulic control system- cutting


Application:

Galvanzied Metal Steel Floor Deck Roll Forming Machine

This type of sheet can be widely used in plant, house, storage and simple steel roof. It has advantage of pretty appearance, durable using and so on.



Competitive Advantage

1. operations safety

2. nice appearance, high quality

3. reasonable price

4. CE certification

5. ISO certification
